Steel Detailing
Detailed to AISC conventions and the reviewing engineer’s requirements, with design conflicts raised as RFIs before they result in a rejected submittal.
Shop Drawings.
Built for Approval.
Coordinated steel, rebar, MEP and millwork drawings, detailed to your project requirements and ready for review.
Detail
Detailed for Review.
Ready for Production.
We detail to the code, the specification and the reviewing engineer’s requirements. Design conflicts are raised before they become rejected submittals.
Specialisms
Overview of Shop Drawings
Rebar Detailing
Reinforcement detailing with quantities reconciled to the schedule and congestion resolved at detailing stage rather than at the pour.
MEP Shop Drawings
Packages released to the shop have already passed clash detection in a federated model.
Millwork & Joinery
Dimensioned to actual material thicknesses and specified hardware, not nominal values.
“The coordinated drawing package gave our reviewers clear information for approval and fabrication.”
Adrian ColeFabrication Manager
88+ 5-Star Reviews
Shop Drawings
Production detailing for steel, reinforcement, MEP and millwork packages, coordinated with approved design information and fabrication requirements.
Ready to discuss your shop drawing requirements?
Get a QuoteWhat You Receive
- Approval and fabrication drawing packages
- Advance and final bills of material
- NC/DSTV output
- IFC model where applicable
- RFI log and submittal register
Specific deliverables are confirmed in your agreed scope.
How It Works
Share Your Requirements
Sign an NDA, then share your project requirements and files.
Confirm Scope and Standards
Agree the scope and standards, then review a pilot before production.
Production & Quality
Shop drawings progress through review checkpoints and documented quality checks.
Review and Handover
Review deliverables and in-scope revisions before final handover.
Frequently Asked Questions
Do you coordinate connections with the engineer of record?
Yes. Connection coordination and the associated RFI process are part of the engagement.
Can you produce NC files for our machines?
Yes — NC/DSTV output is issued alongside the drawing package where the fabricator requires it.
Do you handle resubmittals?
Yes, and in-scope revisions are included until the package is accepted.
